DEV 1000 Multi Fully Automatic Packaging Machine

Technical Specifications:

• The machine is equipped with a multihead weighing system.
• The number of heads in multihead weighers can vary between 10, 14, 18, and 24 depending on the product and weight.
• Products that are difficult to weigh, such as nuts, ravioli, noodles, raisins, and salads, can be easily packaged with multihead weighing systems.
• The main chassis under the multihead weighing system is made of a single-piece frame with a thickness of 6 mm.
• The packaging unit is designed to be fully pneumatic or servo-controlled.
• An air shaft is used in the packaging unit's film attachment rollers.
• The pallets that pull the packaging film are supported by a special rail system.
• Minimum and maximum weight ranges are determined according to the number of heads in the multihead weighing unit.
• All materials used in the weighing and packaging units are made of 304 stainless steel, suitable for food contact.
• Since the weighing unit and the packaging unit operate independently, the error margin in weight is minimized.
• The most important factor in multihead weighing systems is obtaining the weight without errors.
• Multihead weighers can handle more packages than other weighing systems.
• The packaging unit's display can report the number of packages produced during operation.
• The flow of products to the weighing unit is provided by a bucket elevator.

Machine Dimensions:

• Width: 2300 mm
• Length: 2500 mm
• Height: 4000 mm (Including the height of the elevator)

Operating Weight:

• (10 heads) 0-1000 g

Capacity:

• (10 heads): 40-60 packages/minute (Capacity may vary depending on weight and product)

Electrical Power:

• 380V-50Hz

Air Pressure:

• 6-8 Bar

Energy Consumption:

• 3 kW/h
