Technical Specifications:

• Capacity: 0 – 45 cycles
• Max. Forming Area: 750 x 500 mm
• Sheet Material Width: 780 mm
• Sheet Material Thickness: 2 mm
• Pitch: 520 mm
• Clamping Force: 32,500 daN
• Forming Depth: 150 mm
• Compressed Air Requirement: 9 m³, 8 bar
• Electrical Power Requirement: 222.11 kW (at full load)
• Water Pressure and Temperature: 3.4 bar, 8?C, 50,000 kcal
• Weight: 15 tons
• Usable Materials: PP, PS, PET, ABS, PE
• Number of Heaters: 152 longitudinal top, 132 bottom
