Technical Specifications

Printing Combinations

• 4 Colors: 4+0; 3+1; 2+2
• 6 Colors: 6+0; 5+1; 4+2; 3+3
• 8 Colors: 8+0; 7+1; 6+2; 5+3; 4+4

Production Speed

• Maximum: 180 pcs/min (Please check the measurement table)

Material Width

• Maximum: 850 mm

Printing Width

• Maximum: 840 mm

Printing Repeat

• Range: 450-1500 mm

Plate and Tape Width

• Plate Width: 2.54-0.5 mm
• Tape Width: Maximum 5.5-0.1 mm

Position Registration Adjustment

• Lateral: +/- 20 mm
• Longitudinal: Controlled via servo drive unit through touch screen

Ink Transfer System

• Anilox Rollers: Specially designed ceramic anilox rollers
• Ink Pumps: Pneumatically activated ink pumps
• Automatic Print Size Adjustment: Using touch panel
• Anilox Roller Usage: Easy operation by separating and approaching the ceramic anilox from the pressure roller with a single button

Additional Systems

• Chambered Doctor Blade System: Functional and made of aluminum material
• Hot Air Drying System: Exhaust unit, fully inverter-controlled servo units between color changes
• Automatic Reel Change Mechanism: With double winding and unwinding system
• Corona Unit: For double-sided application
• Printing Control System: Double-sided
• Tension Control Unit: Automatic
• Web Edge Control: Automatic

Optional Extras

• Automatic Viscosity Control Unit
• Anti-Static Unit
• Web Surface Cleaning Unit
