AK1100 Perforated Roll Bag Machine Technical Specifications

Suitable Materials:

• LLDPE, LDPE, MLDPE, HDPE, EVA, CPP, OPP, PP, PE, and PA

Film Thicknesses:

• Minimum: 50 microns (2×20 - Double layer, Tube form)
• Maximum: 1000 microns (2×500 - Double layer, Tube form or 4×250 - Four layer, Gusseted tube form)

Film Lengths:

• Minimum: 5 cm (50 mm)
• Maximum: 9999.9 cm (999999 mm)

Control and Display:

• PLC controlled operator control panel
• Touchscreen TFT display

Unwinder and Rewinder:

• Single unwinder, Single rewinder
• Air Shaft Bobbin Holders

Heaters and Sealing System:

• Three independent heater wires (heaters) controlled by a digital impulse system.
  • 1st heater – 2nd heater
  • 1st and 3rd heaters
  • 2nd and 3rd heaters

Perforation and Transfer:

• Perforation only without sealing is possible.
• Transfer only without length measurement is possible.

Bobbin Loading Capacity:

• Maximum bobbin diameter on unwinder shaft: 800 mm
• Maximum bobbin diameter on rewinder shaft: 550 mm
• Maximum bobbin weight on unwinder and rewinder shafts: 250 kg
• Shaft diameter (unwinder/rewinder): 70 mm
• Inner diameter: 76 mm (for cardboard bobbin)

Motor and Control Systems:

• A.C. Motor control speed drivers
• Digital output counter (mm measured)
• Warning for heater wire breakage
• Emergency automatic stop system with reflective photocell

Optional Features:

• Color photocell for printed products can be added.
• Static electricity receiving bar.
• Banana Roller for smooth winding.
• Air blowing system for the sealing jaw.

Power and Air Consumption:

• Power consumption during operation: 1.0-2.5 kW
• Total power: 3P 380V+N+MP, 7.30 kW, 50Hz
• Total air requirement: 8 – 10 bar

Additional Features:

• Shaft locking system
• Sealing quality and production speed may vary depending on the micron thickness and quality of the material being processed.

These technical specifications provide detailed information on the performance and functionality of the AK1100 Perforated Roll Bag Machine.
