AK1800  Perforated Roll Bag Machine

Technical details:

Suitable Materials: This machine can work with a variety of materials such as LLDPE, LDPE, MLDPE, HDPE, EVA, CPP, OPP, PP, PE and PA. Heavy-duty bags can be produced from roll to roll using these materials.

Film Thicknesses:

Minimum: 40 microns (2x20 microns - Double layer Pipe form).
Maximum: 1000 microns (2x500 microns - in tube form or 4x250 microns - in bellows tube form).
Film Lengths:

Minimum: 5cm (50mm).
Maximum: 9999.9 cm (999999 mm).
Control Panel: PLC controlled operator control panel includes touch TFT screen.

Coil Holders: Single unwinder, double winder with air shaft.

Resistance Wires: Three separate resistance wires (heaters) are controlled independently by a digital impulse system. These are divided into 1st heater, 2nd heater and 3rd heater and the following combinations are possible:

and 2nd heaters
and 3rd heaters
and 3rd heaters
Other Features:

Only perforation can be done without welding.
Only transfer is possible without metering.
A maximum diameter bobbin of 950 mm can be loaded on the unwinding shaft and a maximum diameter of 600 mm can be loaded on the winding shaft.
A maximum of 300 kg of bobbin weight can be loaded on both shafts.
Shaft (winder/unwinder) diameter: Outer diameter 70 mm, inner diameter 76 mm (for cardboard bobbin).
HUNGRY. Motor control speed drives.
Digital output counter (with mm meter).
Warning system in case of resistance wire breakage.
Emergency automatic stop system with reflective photocell.
Optional: Color photocell can be added for printed products.
Optional: Static electricity receiver bar.
Banana Roller for smooth winding.
Air blowing system for the chin.
Power and Air Requirement:

Power consumption during operation: between 1.0 and 2.5 kW.
Total power: 3P 380V+N+MP, 8.80 kW, 50Hz.
Total air requirement: 6 - 8 bar.
Additional Features:

It is possible to produce two separate bags with side openings on two separate coils with a cold knife.
Shaft lock system.
Coil loading system for solvent.
This machine is a model designed in accordance with high quality and efficiency standards and has a wide range of uses in plastic film production processes.
